ZWO

ASI 290MM Monochrome Astronomy Camera


  • 39900

This item is out of stock but you can place an order now and we’ll ship when it becomes available.


Description

The ZWO ASI 290MM monochrome camera features the Sony IMX290/291 sensor. This has excellent sensitivity and has boosted QE in the near infrared spectrum. The fast frame rates possible with the USB3.0 version make this an ideal planetary imaging camera.

Specifications

Sensor: 1/2.8″ CMOS IMX290/IMX291

Resolution: 2.1Mega Pixels 1936×1096
Pixel Size: 2.9µm
Exposure Range: 32µs-2000s
ROI: Supported
ST4 Guider Port: Yes
Focus Distance to Sensor: 12.5mm
Shutter Type: Rolling Shutter
Protect window: AR coated window
Operating System Compatibility: Mac, Windows, Linux
Interface: USB3.0/USB2.0
Bit rate: 12bit output(12bit ADC)
Adaptor: 2″ / 1.25″ / M42X0.75
Dimension: φ62mm X 36mm
Weight: 120g or 4.2 ounces (without lens)
Working Temperature: -5°C—45°C
Storage Temperature: -20°C—60°C
Working Relative Humidity: 20%—80%
Storage Relative Humidity: 20%—95%

Supported resolution

USB2.0 MAX FPS
1936×1096: 20.4
1280×960: 35.3
640×480: 141.5
320×240: 355.9
2X2Bin :968×548: 20.4

USB3.0 MAX FPS(12bit/10bit)
1936×1096: 82.2/170
1280×960: 93.6/193.9
640×480: 184/381.2
320×240: 355.9/737.5
2X2Bin :968×548: 82.2/170

More resolutions can be user defined
