CenterLine 14 Position Dual Color Filter Wheel (CL-1-14)
CenterLine 14 Position Dual Color Filter Wheel (CL-1-14)
CenterLine 14 Position Dual Color Filter Wheel (CL-1-14)

FLI

CenterLine 14 Position Dual Color Filter Wheel (CL-1-14)

Regular price
$ 3,975.00
Sale price
$ 3,975.00
Unit price
per

This item is a Special Order from the Manufacturer

Special Order

Description

Color Filter Wheels
FLI color filter wheel’s robust mechanical design provides the basis for stunning, uncompromising images. Each FLI color filter wheel is precision engineered with a highly accurate no-slip drive chain and stepper motor. The large diameter pivot pin and bushings are precision ground and matched for smooth, quiet no-fuss operation night after night. FLI color filter wheels do not use internal lights for homing, so your images are protected from stray light interference.



Specifications

Fourteen Position Dual Color Filter Wheel (CL-1-14)
Number of Filter Wheels: Two
Filter Positions: Twelve + Two Open Positions
Recommended Filter Size (+/- 0.125mm): 2 inch or 50 mm diameter
Filter Thickness Range: 1.0 - 5.0 mm
Overall Thickness (less motor): 27.9 mm
Camera Side Connection: 3.43" CL ZTA
Optical Side Connection: 3.43" CL ZTA
Internal Wheel Material: Aluminum
Interface: USB
Power: 12V
Weight: 4.3 lbs (1.95 kg)
Download Drawing: PDF Drawing
